GGTPA Range

Heavy-Duty Granulator | Plastic Crusher Machines

V Blades Granulator Machines GGTPA-1200-60

Main Features

Reliable performance, high capacity output.

Able to granulate & recycle all kinds of plastics materials of different textures and shapes. Well con-structured with precisely engineered mechanical parts to insure precision. Strong structured, easy to operate, low electricity consumption & durable. Full safety devices installed, to  insure safe operation. V-Blade design external bearing housings, housing installed outside of main body, effectively preventing the granulated material inter into the bearing box, improve bearing life. Hydraulic motor opening and closing device 1.5kw motor.



Machine Specifications

Model



Revolving Blades (pcs)



Fixed Blades
(pcs)



Screen

Dia (mm)



Valid

Mouth (mm)

Capacity

Power

(kw)



Outline

Dimension

(mm)



Machine

Weight (kg)

Blower

Motor

Pipe

Diameter



Silo

Volume

GGT1200*60 10 4 12 300*1200 600*900 75 2300*2150*3350 5500 7.5 127 200


Plastic Materials These Machines Can Granulate
